Fluke IDA-1S Infusion Device Analyzer
SKU 4468525
In stock
$3,999.99
Price excludes freight and applicable tax. Volume pricing available on multiple units.
Purchase orders and net terms available for hospitals and government buyers.
Function tested
Electrical safety + function check on file
[warranty term]
Term set per condition tier
Ships in
[lead time]
Crated freight on capital equipment
Returns accepted
[return window]
Overview
The Fluke Biomedical IDA-1S Infusion Device Analyzer gives biomedical technicians a portable one-channel tester for infusion pump performance verification, preventive maintenance, incoming inspection, and service checks. It measures flow rate, delivered volume, and occlusion pressure , which helps service teams confirm pump output before returning infusion devices to use. REF 4468525 identifies the IDA-1S one-channel configuration.
The IDA-1S works with a wide range of infusion devices, including syringe, drop-counting, peristaltic, volumetric, and non-steady flow-rate pumps. In addition, the auto-start function begins testing when fluid is detected, which helps with syringe pumps and other tests that have long startup times.
The analyzer supports average flow measurement, instantaneous flow measurement, volume measurement, and occlusion pressure testing up to 45 psi . It also includes onboard memory for result storage and HydroGraph software support for PC control, graphing, printing, and test documentation.
Key Features
- Fluke Biomedical IDA-1S infusion device analyzer
- Reference number: 4468525
- One-channel infusion pump analyzer
- Measures flow rate and delivered volume
- Measures occlusion pressure up to 45 psi
- Flow rate range: 0.5 mL/h to 1000 mL/h
- Volume range: 0.06 mL to 999 mL
- Auto-start mode begins testing when fluid is detected
- LCD touchscreen interface
- Onboard memory stores test results
- HydroGraph V3 software support
- USB data transfer cable support
- Battery-powered operation up to 10 hours
- Charger input: 100 V AC to 240 V AC, 50/60 Hz
- Approximate size: 30 cm x 17 cm x 10 cm
- Approximate weight: 1.2 kg / 2.7 lb
Specifications
| Manufacturer | AKB Medical |
|---|---|
| Model / part number | 4468525 |
| Warranty | awaiting data |
| Power supply | awaiting data |
| Dimensions (W × H × D) | awaiting data |
| Weight | awaiting data |
What's included
Populate from the whats_included metafield: main unit, power supply, patient cables, battery, manuals and any mounting hardware shipped with this configuration.
Documents
Datasheets, operator manuals and test records appear here once product files are attached.
Shipping, warranty & returns
Shipping
Accessories ship via ground carrier. Capital equipment ships crated on a pallet with freight class declared and tracking supplied.
Warranty
Warranty term varies by condition tier and is shown on this page when the product metafield is populated.
Returns
Return window, restocking fee and RMA process are confirmed per product when available.
Payment & terms
Card, ACH and wire. Purchase orders and net terms for approved hospital, government and education accounts.
