Fluke ESA609 Electrical Safety Analyzer
SKU ESA609
In stock
$3,499.99
Price excludes freight and applicable tax. Volume pricing available on multiple units.
Purchase orders and net terms available for hospitals and government buyers.
Function tested
Electrical safety + function check on file
[warranty term]
Term set per condition tier
Ships in
[lead time]
Crated freight on capital equipment
Returns accepted
[return window]
Overview
The Fluke ESA609 Electrical Safety Analyzer is a compact biomedical test device for general electrical safety testing of medical equipment. It helps biomedical technicians, clinical engineering teams, and service providers check electrical safety during preventive maintenance, incoming inspection, equipment repair, and routine service verification.
The ESA609 performs key electrical safety tests, including mains voltage, ground wire resistance, equipment current, leakage current, and point-to-point testing . It supports safety test selections for ANSI/AAMI ES1, NFPA-99, IEC 62353, and IEC 60601-1 , which makes it useful for healthcare facilities and biomedical service programs that need a portable analyzer for common safety checks.
The analyzer operates with both 120 V and 230 V power configurations and can test equipment current up to 20 A . Its lightweight body, rubberized case, tilt stand, and quick push-button operation make it practical for field service, hospital rounds, and tight equipment areas.
Key Features
- Fluke Biomedical ESA609 electrical safety analyzer
- U.S. reference number: 4375516
- U.S. model: ESA609-US
- Portable electrical safety analyzer for biomedical equipment testing
- Supports ANSI/AAMI ES1, NFPA-99, IEC 62353, and IEC 60601-1 test selections
- Mains voltage measurement
- Ground wire / protective earth resistance testing
- Equipment current testing up to 20 A
- Leakage current testing
- Point-to-point testing
- 120 V and 230 V operation, configuration dependent
- Manual operation with push-button interface
- LCD display
- Rubberized case with IP30 rating
- Lightweight design: 0.7 kg / 1.5 lb
Specifications
| Manufacturer | AKB Medical |
|---|---|
| Model / part number | ESA609 |
| Warranty | awaiting data |
| Power supply | awaiting data |
| Dimensions (W × H × D) | awaiting data |
| Weight | awaiting data |
What's included
Populate from the whats_included metafield: main unit, power supply, patient cables, battery, manuals and any mounting hardware shipped with this configuration.
Documents
Datasheets, operator manuals and test records appear here once product files are attached.
Shipping, warranty & returns
Shipping
Accessories ship via ground carrier. Capital equipment ships crated on a pallet with freight class declared and tracking supplied.
Warranty
Warranty term varies by condition tier and is shown on this page when the product metafield is populated.
Returns
Return window, restocking fee and RMA process are confirmed per product when available.
Payment & terms
Card, ACH and wire. Purchase orders and net terms for approved hospital, government and education accounts.
Questions about this unit?
Send the model and your configuration. We confirm compatibility, condition and lead time before you raise a PO.
Ask about this product
