BC Group ESU-2400 Electrosurgical Unit Analyzer
SKU ESU-2400H
In stock
$8,499.99
Price excludes freight and applicable tax. Volume pricing available on multiple units.
Purchase orders and net terms available for hospitals and government buyers.
Function tested
Electrical safety + function check on file
[warranty term]
Term set per condition tier
Ships in
[lead time]
Crated freight on capital equipment
Returns accepted
[return window]
Overview
The BC Group ESU-2400 Electrosurgical Unit Analyzer tests ESU generator output, leakage, power, crest factor, pulse timing, load curves, and REM/ARM/CQM performance.
Key Features
- BC Group / BC Biomedical ESU-2400 electrosurgical analyzer
- High-accuracy True RMS RF measurement system
- Designed for electrosurgical generator calibration and performance verification
- Internal low-reactance load bank: 0 to 6400 ohms
- Load selection resolution: 1 ohm
- RF frequency range: 10 kHz to 10 MHz
- Maximum input voltage: 10 kV
- Power measurement range: 0 to 999.9 W
- Current measurement range up to 7000 mA RMS
- Crest factor range: 1.4 to 500
- Pulse mode timing resolution: 0.1 ms
- Pulse timing accuracy: ±0.2 ms
- True RMS readings using DFA technology
Specifications
| Manufacturer | AKB Medical |
|---|---|
| Model / part number | ESU-2400H |
| Warranty | awaiting data |
| Power supply | awaiting data |
| Dimensions (W × H × D) | awaiting data |
| Weight | awaiting data |
